Shure UA874WB Active Directional Antenna (470-900mhz)

Shure
S$749.00
Current Stock:
0
SKU:
UA874WB

Improve wireless signal reception for UHF wireless systems with the Shure UA874WB, a wideband active directional antenna with a frequency range extending from 470 to 900 MHz. The antenna uses a log periodic dipole array to produce a cardioid pattern towards the desired coverage area with greater rejection of RF signals outside the coverage area when compared to standard 1/2-wave omnidirectional antennas.

An integrated amplifier with four gain settings compensate for varying degrees of coaxial-cable signal loss.

The UA874WB can be stand-mounted, suspended from the ceiling, or wall-mounted using the integrated swivel adapter bracket.

Key Features
  • Shure quality, ruggedness, and reliability
  • Compatible with Shure wireless receivers and antenna distribution systems that provide 10 to 15 VDC bias current
  • Four-position gain selector switch
  • Integrated threaded adapter mounts easily to microphone stands
  • Low-noise signal amplifier compensates for insertion loss in coaxial cable

Technical Specifications

  • RF Frequency Range: 470 to 900 MHz
  • Connector Type: BNC, Female
  • Impedance: 50 Ohms
  • Reception Pattern: 70°, 3 dB Beam Width
  • Third-order Overload Intercept Point: OIP3: >30 dBm
  • Antenna Gain: 7.5 dBi, On Axis
  • Signal Gain:
    • Switchable
    • Active: +12 dB, +6 dB (±1 dB)
    • Passive: 0 dB, -6 dB (±1 dB)
  • RF Overload LED Threshold: -5 dBm, RF Overload LED Does Not Operate for Passive Gain Settings
  • Power Requirements: 10 to 15 VDC Bias from Coaxial Connection, 75 mA
  • Operating Temperature Range: 0 to 145°F / -18 to 63°C
  • Storage Temperature Range: -20 to 165°F / -29 to 74°C
  • Dimensions: 14.1 x 12.4 x 1.4" / 359 x 316 x 36 mm
  • Weight: 11.2 oz / 317 g

2 year warranty from date of purchase. Headphones SG is a SHURE authorised reseller. All SHURE products purchased through Headphones SG is eligible for warranty.
